Inflammatory myofibroblastic tumor in the pancreatic neck: a rare case report and literature review

Introduction

Inflammatory myofibroblastic tumor (IMT) is a rare mesenchymal tumor with recurrence potential. In 1990, the concept of IMT was proposed by Pettinato et al. (1), and it was officially named by the World Health Organization (WHO) in 2002. IMT is composed of differentiated myofibroblastic spindle cells, usually accompanied by a large number of plasma cells or lymphocytes (2). The cause of IMT is unknown. It may be related to the recombination of the ALK gene of the 2p23 chromosome (3), or may be related to surgery, trauma, inflammation, Epstein-Barr virus (4,5), and herpes simplex virus infection (2,6,7), amongst other factors. It shows a wide anatomical distribution, most frequently arising in the abdominal soft tissues, followed by the lung, and unusual locations include somatic soft tissues, pancreas, liver, and the central nervous system (CNS). The site of origin determines symptoms, and as many as one third of patients have a clinical syndrome, possibly cytokine-mediated, including fever, malaise, and weight loss, as well as laboratory abnormalities including anemia, thrombocytosis, and elevated erythrocyte sedimentation rate (8). Its clinical manifestations are atypical and imaging examinations are not specific. This makes preoperative diagnosis difficult, and it is likely to be misdiagnosed as a malignant tumor. Surgical resection is the preferred treatment. IMT of the pancreas is very rare. Herein, we report a case of IMT that occurred in the neck of the pancreas, discussed the relevant characteristics of pancreatic IMT, and reviewed the literature. To the best of our knowledge, IMT located in the neck of the pancreas has been rarely reported. We present the following article in accordance with the CARE reporting checklist (available at http://dx.doi.org/10.21037/gs-21-303).

Case presentation

A 57-year-old female patient was admitted to the hospital on August 7, 2020, with intermittent abdominal pain for 2 months. The patient complained of pain in the right upper abdomen for no obvious reason 2 months ago, and the pain was obvious at night and relieved during the day. She underwent an abdominal ultrasound examination at the local hospital 2 weeks ago, and multiple gallbladder stones with inflammation and liver cysts were found. After conservative treatment, her symptoms eased slightly. She was seen at Anshan Central Hospital 1 week ago, and dynamic computed tomography (CT) of her abdomen revealed a space-occupying pancreatic lesion. During this time, she lost 3kg in weight, without fever, vomiting, jaundice, melena, and other symptoms. Her blood pressure was 135/73 mmHg and heart rate was 70/min. There was no personal or family history. On physical examination, there was tenderness in the right upper abdomen, Murphy’s sign was positive, and the patient’s bowel sounds were normal. No special condition was found in other whole-body system examinations. Esophageal inflammation changes and atrophic gastritis were found in upper gastrointestinal endoscopy. Her WBC count was 4.95×10⁹/L, hemoglobin was 135 g/L, and her tumor markers (CEA: 4.19 ng/mL, AFP: 2.07 ng/mL, CA-125: 3.15 U/mL, CA-19-9: 12.80 U/mL) were all within the normal range.

CT showed that there was a circular low-density shadow with a diameter of 1.9 cm in the neck of the pancreas, and in contrast-enhanced CT, the mass was enhanced unevenly. It was highly suspected that this space-occupying lesion was a solid pseudopapillary tumor of the pancreas. There was a 1.4-cm-diameter round type of obvious enhancement in the right lobe of the liver, and it was unclear in the delayed phase. The gallbladder was not large, the gallbladder wall was thickened and strengthened, and multiple dense shadows were seen inside. CT suggested liver cysts and gallbladder stones with cholecystitis. Abdominal magnetic resonance imaging (MRI) showed that there was nodular long T1 and long T2 signal changes in the pancreas neck, the size was about 1.1 cm × 1.9 cm, and the enhancement showed uneven enhancement, which was lower than the surrounding pancreatic tissue. MRI showed a high possibility of solid pseudopapillary tumor of the pancreas. For the liver and gallbladder, MRI also had corresponding manifestations, and like CT, it suggested liver cysts and gallbladder stones.

At this point, the diagnosis of the patient was initially clear, but the nature of the pancreatic neck tumor was yet to be clarified. It remained to be determined whether it was a solid pseudopapillary tumor with high suspicion on CT and MRI imaging, other benign tumor of the pancreas, or a pancreatic malignant tumor. For diagnosis and treatment, laparoscopic surgery was performed on the patient. Firstly, under laparoscopy, it was found that the gallbladder showed chronic inflammation and adhered to the surroundings. The gallbladder was peeled along the gallbladder plate with an ultrasonic knife, and the gallbladder was removed. Later, after the pancreas was exposed, the tumor was found in the neck of the pancreas, leaning toward the head of the pancreas, about 2.0 cm × 2.5 cm in size, with no infiltration in the surrounding area. During the operation, lymph nodes of groups 7, 8, and 9 were seen to be enlarged, and the frozen pathological results during the operation showed that the lymphatic tissue had proliferated, and no cancer was found. The patient underwent middle pancreatectomy. The tumor specimen was completely taken out during the operation, and the tumor envelope was intact (Figure 1A,B). After the specimen was cut open, it was found to be substantial, hard, and tough (Figure 1C). Intraoperative frozen pathology showed mesenchymal tumor, prone to aggressive fibromatosis. Immunohistochemical staining features suggested IMT. Two weeks after the operation, the patient was discharged from the hospital without complications.

Figure 1 Photograph of the resected specimen. (A,B) The tumor specimen was completely taken out during the operation, and the tumor envelope was intact; (C) after the specimen was cut open, it was found to be substantial, hard and tough.

All procedures performed in studies involving human participants were in accordance with the ethical standards of the institutional and/or national research committee(s) and with the Helsinki Declaration (as revised in 2013). Written informed consent was obtained from the patient. The study was approved by Ethics Committee of the First Affiliated Hospital of China Medical University

Discussion

IMT is a rare disease. In the past, IMT was also called plasma cell granuloma, inflammatory pseudotumor, inflammatory pseudotumor, inflammatory myofibrohistiocytic proliferation, omental-mesenteric myxoid hamartoma, and inflammatory fibrosarcoma. It was defined, in the fifth edition of the 2020 WHO classification of soft tissue and bone tumors, as a distinctive, rarely metastasizing neoplasm composed of myofibroblastic and fibroblastic spindle cells accompanied by an inflammatory infiltrate of plasma cells, lymphocytes, and/or eosinophils (9). There is generally no difference in the incidence of IMT in men and women, though females may have a slight predominance. IMT that occurs in the pancreas is quite rare, and while it can be located anywhere in the pancreas, it usually occurs in the head of the pancreas (10). In case reports of pancreatic IMT before 2004, 60% of cases occurred in the head of the pancreas (10). In 2019, Matsubayashi et al. (11) searched PubMed for pancreatic IMT. After screening, there were only 27 cases of pancreatic IMT confirmed by histology, of which 20 cases were located in the head of the pancreas. IMT occurring in different locations of the pancreas may result in different clinical symptoms, but pancreatic IMT has no specific clinical symptoms and usually has no clinical symptoms or presents with general gastrointestinal symptoms such as abdominal pain, loss of appetite, nausea, and vomiting (10-12). This may be caused by the mass compressing the surrounding organs, such as the duodenum. In a few other cases, pancreatic IMT may manifest as anemia, fatigue, palpable mass, and diabetes, similar to pancreatic cancer and pancreatic neuroendocrine tumors (12). Interestingly, there was a case of pancreatic IMT reported showing extracolonic obstruction (13). There are also cases which present as acute pancreatitis (14,15). In our case, IMT occurred in the neck of the pancreas, and the lump size was only 2.0 cm × 2.5 cm. Abdominal pain was the only clinical symptom of the patient. However, the patient was found to have gallstones and chronic cholecystitis, the right upper abdomen was tender, and Murphy’s sign was positive. Therefore, abdominal pain seems to be caused by cholecystitis, but abdominal pain may not be related to pancreatic IMT.

The cause of IMT is unknown, and IMT is genetically heterogeneous. In 50–60% of IMT cases in children and young adults, there is a clonal cytogenetic rearrangement of the tumor, involving the 2p23 chromosome band, that fuses the 3’ kinase region of the ALK gene with various partner genes. It is a rare mesenchymal tumor with the potential for recurrence, with intermediate biological behavior (low-grade malignancy). The spindle fibroblastic-myofibroblastic cells and inflammatory cells form three basic histological patterns (9), including a myxoid pattern, a hypercellular pattern, and a hypocellular fibrous pattern.

Preoperative diagnosis of IMT is difficult because of its rarity and histological diversity, as well as the lack of specific clinical manifestations and imaging features. At present, there is no biomarker that can help the early diagnosis of IMT. Some pancreatic IMT imaging features are strikingly similar to pancreatic cancer, and most cases mimic malignancies (11), making it difficult to diagnose correctly. At present, CT diagnosis of pancreatic IMT has not been established by a standard or expert consensus. However, the CT of pancreatic IMT usually presents as low-density lesions. After enhancement, it shows uneven delayed enhancement, that is, early enhancement does not enhance or has mild enhancement, and late enhancement further enhances to moderate enhancement. However, in some cases, enhanced CT showed no enhanced mass, suspected to be ductal adenocarcinoma, and finally pathologically confirmed as pancreatic IMT (16). Therefore, the exact enhanced CT diagnostic criteria may be difficult for IMT. MRI of pancreatic IMT usually shows uneven low signal on T1WI, and equal, slightly high, and high signal on T2WI. Enhanced MRI shows uneven enhancement. However, there are also case reports showing low signal on both T1WI and T2WI (17). This may be related to the pathological classification of IMT, in that the greater the proportion of intratumoral stromal edema and mucus collagen degeneration, the higher the signal, and the greater the proportion of spindle cells, the lower the signal. CT can accurately display the blood supply and anatomical characteristics of the lesion, while MRI can help evaluate the composition of the lesion and predict the pathological classification. If an unevenly enhanced soft tissue mass with infringement of adjacent tissue structures and unclear borders is found on the CT image, the possibility of IMT should be considered when diagnosis and differential diagnosis of the tumor at this site are involved. At the same time, ultrasound and CT-guided biopsy is helpful for the diagnosis of IMT, but this diagnosis method is rarely available in clinical practice.

The histological diagnosis of biopsy or intraoperative frozen sections is very difficult, and it is of little help for the diagnosis of IMT due to the vast inflammatory infiltration of the lesion (18). Pancreatic IMT must be differentiated from lymphoma, fibrosarcoma, chronic pancreatitis, and pancreatic cancer (19). The final diagnosis depends on histopathology and immunohistochemical examination (10,20). The WHO’s 2020 essential diagnostic criteria for IMT are as follows: (I) loose or compact fascicles of spindle cells with a prominent inflammatory infiltrate and a variable fibrous or myxoid stroma; (II) expression of ALK (seen in as many as 60% of cases). The desirable diagnostic criterion is ALK or other gene rearrangements (in selected cases). In our case, the CT image showed that the pancreatic neck had a circular low-density shadow with a diameter of 1.9 cm, which was unevenly enhanced after enhancement (Figure 2), but the imaging doctor’s report suggested that the diagnosis was likely to be solid pseudopapillary tumor. However, intraoperative frozen sections suggested invasive fibromatosis. The results were confirmed by pathology and immunohistochemistry, and the final diagnosis was IMT. Evidently, the whole disease diagnostic process was complicated, and highlights the difficulty of preoperative diagnosis of pancreatic IMT.

Figure 2 Enhanced abdominal CT revealed a circular low-density mass. A circular low-density shadow with a diameter of 1.9 cm in the neck of pancreas (pointed by the red arrow).

Surgical resection is the first choice to obtain a clear diagnosis and relieve symptoms, and it is also the only effective method for the treatment of pancreatic IMT. The clinical course of IMT is usually benign, and the tumor’s biological potential is low. Therefore, the treatment of pancreatic IMT is different from the treatment of pancreatic cancer, radiotherapy and chemotherapy are rarely used in the treatment of IMT, and the benefits of chemotherapy and radiotherapy remain to be proven (21). The efficacy of chemotherapy drugs is still controversial (22-24). For highly invasive IMT, the necessity and specific efficacy of radiotherapy and chemotherapy require more large-scale studies to confirm. In addition, there were reports that steroids and non-steroidal anti-inflammatory drugs can be used to treat IMT (25,26). IMT may have local recurrence, but local invasive or malignant lesions with distant metastasis are rare (21). Incomplete resection, such as adhesion of important structures and multifocality, may be an important cause of IMT recurrence (8). IMT that occurs in the abdomen or retroperitoneum has a tendency to be more aggressive, and is more prone to multiple recurrences and distant metastases (21). A study in 2007 showed that ALK-negative IMT may be more likely to metastasize (3).

Typical myofibroblasts have a vesicular nucleus, 1–3 small nuclei, and an eosinophilic cytoplasm, and sometimes appear as ganglion-like nuclei. Necrosis is not common. When malignant transformation occurs, the uniform spindle cells transform into atypical polygonal cells or full cells, the nucleus is bubble-like, the nucleolus is prominent, the proliferation activity is enhanced, and tumor necrosis occurs (8). The mitotic phase and atypia of spindle cells in tumors are closely related to the invasion, metastasis, and recurrence of IMT. If there are many spindle-shaped nuclei in the tumor, it can easily be misdiagnosed as sarcoma or malignant fibrous histiocytoma. If the number of inflammatory cells in the tumor is abnormally increased, it can easily be confused with lymphoma. In our case, we could see local stroma with hyaline degeneration, and found that the typical spindle cells were infiltrated by a large number of inflammatory cells, mainly plasma cells and lymphocytes (Figure 3A,B). Furthermore, tumor cells had grown into surrounding pancreatic tissue (Figure 3C,D). On immunohistochemistry, the tumor was found to be positive for Vimentin (Figure 4A), smooth muscle actin (SMA) (Figure 4B), and CD34 (Figure 4C), but negative for β-catenin (Figure 4D). Some tumor cells had positive expression of Bcl-2 (Figure 4E), and the expression of Ki67 in tumor cells was about 5% (Figure 4F). According to the results of histology and immunohistochemistry, we obtained a final diagnosis of pancreatic IMT. The prognosis of IMT is generally good. In the long-term follow-up of pancreatic IMT, complications rarely occur. During the 6-month follow-up of this case, the patient had no other complications.

Figure 3 Photomicrograph of hematoxylin and eosin staining of the lesion. (A,B) The tumor cells are distributed in bundles or sheets, the cells are fusiform or epithelioid, the nucleus is oval or polygonal, nucleoli are visible, mitotic images are rare, and a lot of inflammatory cell infiltration is seen in the background, mainly plasma cells and lymphocytes. Local stroma with hyaline degeneration (magnification, ×100, ×200 respectively); (C,D) Tumor cells have unclear borders, infiltrate and grow into the surrounding pancreatic tissue, and the pancreatic ducts and pancreatic islets are compressed and deformed (magnification, ×100, ×200 respectively).

Figure 4 Photomicrograph of immunohistochemistry staining of the lesion. (A) Vimentin positive expression in tumor cells, negative expression in internal control pancreatic islet tissue. (B) Tumor cells were positive for smooth muscle actin. Smooth muscle of blood vessels acted as an internal positive control. (C) CD34 positive expression in tumor cells, positive expression in internal control blood vessels. (D) Tumor cells were immunonegative for β-catenin. (E) There are some tumor cells express Bcl-2 positively. (F) The expression of Ki67 in tumor cells is about 5%. Magnification, ×200.

Conclusions

In summary, this case reports a rare case of IMT in the neck of the pancreas. The patient was 57 years old. She only had abdominal pain symptoms and non-specific imaging findings. Even professional imaging physicians made a diagnosis of solid pseudopapillary tumor. Intraoperative rapid frozen sections also failed to accurately diagnose, and the diagnosis ultimately depends on surgical resection, postoperative histopathological examination, and immunohistochemistry. Complete surgical resection is the first choice method to treat IMT. This case highlights the difficulty of preoperative diagnosis of pancreatic IMT, and emphasizes the difficulty of distinguishing it from pancreatic malignancies, even with multimodal investigation. As mentioned previously, preoperative diagnosis is usually incorrect, and most patients usually require surgical exploration and resection to confirm an accurate diagnosis. We hope that through this case report, clinicians can have a deeper understanding of pancreatic IMT.

Acknowledgments

Funding: Liaoning Provincial Department of Education Science Research Project (No. L2014299) and National Natural Science Foundation of China (No. 81572360).

Footnote

Reporting Checklist: The authors have completed the CARE reporting checklist. Available at http://dx.doi.org/10.21037/gs-21-303

Conflicts of Interest: All authors have completed the ICMJE uniform disclosure form (available at http://dx.doi.org/10.21037/gs-21-303). All authors report funding from Liaoning Provincial Department of Education Science Research Project (No. L2014299) and National Natural Science Foundation of China (No. 81572360). The authors have no other conflicts of interest to declare.

Ethical Statement: The authors are accountable for all aspects of the work in ensuring that questions related to the accuracy or integrity of any part of the work are appropriately investigated and resolved. All procedures performed in studies involving human participants were in accordance with the ethical standards of the institutional and/or national research committee(s) and with the Helsinki Declaration (as revised in 2013). Written informed consent was obtained from the patient. The study was approved by Ethics Committee of the First Affiliated Hospital of China Medical University.

Open Access Statement: This is an Open Access article distributed in accordance with the Creative Commons Attribution-NonCommercial-NoDerivs 4.0 International License (CC BY-NC-ND 4.0), which permits the non-commercial replication and distribution of the article with the strict proviso that no changes or edits are made and the original work is properly cited (including links to both the formal publication through the relevant DOI and the license). See: https://creativecommons.org/licenses/by-nc-nd/4.0/.
