Single-incision robotic nipple-sparing mastectomy with immediate breast reconstruction: a comprehensive surgical technique and strategy
Surgical Technique

Single-incision robotic nipple-sparing mastectomy with immediate breast reconstruction: a comprehensive surgical technique and strategy

Ze Huang1,2#, Zuxiao Chen1,2#, Xiaoyan Fu1,2#, Zongyan Li1,2, Zhijie Wu1,2, Qiwen Liu1,2, Lina Wei1,2, Bingfeng Chen1,3, Chan Qiu1,4, Haiyan Li1,2

1Department of General Surgery (Breast Surgery), The Sixth Affiliated Hospital, Sun Yat-sen University, Guangzhou, China; 2Biomedical Innovation Center, The Sixth Affiliated Hospital, Sun Yat-sen University, Guangzhou, China; 3The Breast Center, Cancer Hospital of Shantou University Medical College, Shantou, China; 4Department of Breast Surgery, Nanhai Maternity and Child Healthcare Hospital of Foshan, Foshan, China

Contributions: (I) Conception and design: Z Huang, Z Chen, X Fu, H Li; (II) Administrative support: X Fu, Z Li, H Li; (III) Provision of study materials or patients: Q Liu, L Wei; (IV) Collection and assembly of data: Z Wu, B Chen; (V) Data analysis and interpretation: Z Li, C Qiu; (VI) Manuscript writing: All authors; (VII) Final approval of manuscript: All authors.

#These authors contributed equally to this work.

Correspondence to: Haiyan Li, MD, PhD. Department of General Surgery (Breast Surgery), The Sixth Affiliated Hospital, Sun Yat-sen University, No. 26 Erheng Road, Yuancun, Tianhe District, Guangzhou 510655, China; Biomedical Innovation Center, The Sixth Affiliated Hospital, Sun Yat-sen University, Guangzhou, China. Email: lihy27@mail.sysu.edu.cn.

Abstract: With the increasing application of robotic surgical systems in various surgical fields and the progressive refinement of endoscopic breast surgery, robotic breast surgery has been actively explored and implemented. Robotic surgical platforms offer several advantages, including enhanced flexibility, three-dimensional magnified visualization, high-resolution imaging, and tremor elimination, thereby improving surgical stability and precision, particularly in confined surgical spaces. Given that the breast lacks a natural cavity, robotic surgical systems exhibit a high degree of adaptability for breast surgery. In 2015, Toesca et al. first reported robotic nipple-sparing mastectomy (R-NSM) with immediate breast reconstruction (IBR), which has since become a mainstream approach in robotic-assisted breast surgery. Existing studies have consistently demonstrated that R-NSM with IBR is a safe and feasible procedure, achieving good aesthetic outcomes, high patient satisfaction, and a low complication rate. However, as R-NSM with IBR is still in its nascent stages, particularly, single-incision R-NSM with IBR, the procedure involves intricate and complex surgical steps. The adoption of this novel technology imposes higher requirements on surgical precision, further increasing the procedural complexity. Standardized protocols and systematic workflows for this procedure are yet to be established. In this study, we provide a comprehensive step-by-step description of the entire surgical process of single-incision R-NSM with IBR through an instructional video and text.

Keywords: Robotic nipple-sparing mastectomy (R-NSM); single incision; breast reconstruction; technique; strategy


Submitted Apr 01, 2025. Accepted for publication Jun 25, 2025. Published online Aug 21, 2025.

doi: 10.21037/gs-2025-151


Video 1 Step-by-step demonstration of single-incision robotic nipple-sparing mastectomy with immediate breast reconstruction.

Highlight box

Surgical highlights

• Single-incision robotic nipple-sparing mastectomy (R-NSM) with immediate breast reconstruction (IBR) can be completed entirely through a single axillary incision, resulting in a small and inconspicuous scar, high patient satisfaction, and good aesthetic outcomes. The “deep-to-superficial” surgical sequence, combined with CO2 insufflation, provides an optimal surgical field and sufficient working space. Guided by the theory of breast fascial anatomy and a “defensive strategy”, this technique may achieve favorable surgical outcomes.

What is conventional and what is novel/modified?

• The conventional nipple-sparing mastectomy is open surgery.

• We perform R-NSM with IBR through a single axillary incision, utilizing a “deep-to-superficial” surgical sequence. The procedure is guided by the theory of breast fascial anatomy.

What is the implication, and what should change now?

• For selected patients, single-incision R-NSM with IBR represents a viable alternative to open surgery or endoscopic approaches. Further studies with larger cohorts and longer follow-up periods are required to validate the clinical value and long-term oncological safety of single-incision R-NSM with IBR.


Introduction

Breast cancer is the most common malignancy among women worldwide (1). In China, it is the second most frequently diagnosed cancer among females, accounting for approximately 18.4% of global breast cancer cases (2). Notably, the incidence rate of breast cancer in China is increasing at twice the global average, with a significant trend of younger age at diagnosis (3,4). The breast, as a vital component of female identity and self-esteem, plays a crucial role in women’s psychological well-being. Breast surgical treatment that maintains physical aesthetics is closely associated with patients’ quality of life and represents one of the fundamental objectives in modern breast cancer management. As the cornerstone of comprehensive breast cancer treatment, surgical approaches have evolved from focusing on extensive resection to the emphasizing minimally invasive and effective techniques. The current surgical idea aims to enhance postoperative aesthetic outcomes and quality of life while ensuring oncological safety (5,6).

Minimally invasive surgery has become the mainstream of modern surgical practice, with endoscopic and robotic techniques deeply integrated into the surgical management of breast tumors (7,8). Conventional nipple-sparing mastectomy (C-NSM) with immediate breast reconstruction (IBR) has undergone significant innovation, leading to the widespread adoption of endoscopic NSM (E-NSM) and robotic NSM (R-NSM) with IBR (9). Minimally invasive NSM (MI-NSM) accomplishes all surgical procedures through inconspicuous small incisions while maintaining the equivalent resection scope to C-NSM. This approach results in reduced postoperative pain, superior aesthetic outcomes with scar-free breast skin, ultimately improving patient satisfaction and quality of life. Furthermore, MI-NSM demonstrates lower postoperative complication rates, particularly a significant reduction in nipple-areola complex (NAC) necrosis, along with faster wound healing (7,10-12).

The robotic surgical systems have further advanced minimally invasive breast surgery by providing high-definition, three-dimensional magnified visualization and highly flexible robotic arms capable of 540° rotation (13,14). These features enable extensive surgical procedures through small incisions, overcoming the spatial constraints of narrow surgical fields and addressing various technical challenges associated with endoscopic surgery (15,16). Studies have demonstrated that R-NSM is a safe and feasible approach (9,11,17). Compared to E-NSM, R-NSM is associated with reduced intraoperative blood loss, higher patient satisfaction with surgical incisions, and a significantly shorter learning curve, estimated at 10–15 procedures (7,9,18,19). However, as robotic breast surgery is still in its early stages, the availability of robotic surgical systems is currently limited to a select number of large-scale medical institutions. Moreover, the standardized and systematic surgical protocols for robotic breast surgery have not yet been fully established, which may impact the reproducibility and safety of surgical outcomes across different institutions (13,20). Here, we provide a detailed and comprehensive description of the surgical procedure for single-incision R-NSM with IBR through a case report video (Video 1) and accompanying text. This includes critical surgical techniques, strategic considerations, and key technical points, aiming to contribute to the establishment of standardized and systematic surgical protocols. We present this article in accordance with the SUPER reporting checklist (available at https://gs.amegroups.com/article/view/10.21037/gs-2025-151/rc).


Preoperative preparations and requirements

The patient underwent the surgical procedure at The Sixth Affiliated Hospital, Sun Yat-sen University using the da Vinci Xi surgical system (Intuitive Surgical, Sunnyvale, CA, USA). The surgical team consisted of one surgeon, two assistants, one anesthetist, one scrub nurse, and one circulating nurse. All procedures performed in this study were in accordance with the ethical standards of the ethics committee of The Sixth Affiliated Hospital, Sun Yat-sen University and with the provisions of the Declaration of Helsinki and its subsequent amendments. Written informed consent was obtained from the patient for the publication of this article, accompanying images and the video. A copy of the written consent is available for review by the editorial office of this journal.

The patient underwent physical examination, breast ultrasound, mammography, and magnetic resonance imaging to evaluate the breast and axillary conditions. Liver ultrasound, chest computed tomography (CT), and head CT were performed to assess distant metastases. The inclusion criteria for single-incision R-NSM with IBR were early-stage breast cancer with a tumor diameter <5 cm and no multiple lymph node metastases; breast size ≤ C cup with no severe ptosis; patients with high aesthetic demands who voluntarily opted for single-incision R-NSM with IBR; and prophylactic mastectomy. Exclusion criteria included tumor invasion of the NAC, skin, or chest wall; inflammatory breast cancer; and poor systemic conditions rendering the patient unable to tolerate surgery (12,18,21).


Step-by-step description

The patient was a 42-year-old female patient with a body mass index of 23.15 kg/m2. Ultrasound examination revealed multiple solid nodules in the right breast, including a hypoechoic lesion at the 1–2 o’clock position measuring up to 25 mm, which was classified as Breast Imaging Reporting and Data System (BI-RADS) category 6. CT scan revealed a nodule in the upper inner quadrant of the right breast, with a suspected malignancy. The lesion was classified as BI-RADS category 6. No abnormal lymphadenopathy was observed in the axilla. Pathological examination of the core needle biopsy confirmed ductal carcinoma in situ. Preoperative evaluation excluded distant metastasis. She had no history of smoking nor alcohol consumption and was deemed suitable for general anesthesia and surgery. The images and video are solely for academic and educational purposes.

Step 1: preoperative surgical planning

The patient was positioned standing with hands on the hips, head held high, gaze directed forward, and feet shoulder-width apart. The surgeon should mark the projected location of the mass on the breast skin, clearly delineate the anatomical boundaries of the breast and the planned resection margins (Figure 1).

Figure 1 Preoperative drawings. (A) The image shows the frontal view of the preoperative breast appearance and preoperative drawings; (B) The image shows the lateral view of the preoperative breast appearance and preoperative drawings.

Step 2: anesthesia and positioning

After inducing general anesthesia and performing tracheal intubation, the patient was positioned in the supine position with the affected side adjacent to the edge of the operating table. Elevate the affected side using appropriate padding and maintain the ipsilateral upper extremity in 90° abduction. Sterilize the surgical site with povidone-iodine skin disinfectant, then wrap the upper extremity with sterile drapes and secure it in 90° abduction.

Step 3: sentinel lymph node biopsy (SLNB)

Prepare the sentinel lymph node tracer by aspirating a 1:1 mixture of carbon nanoparticles and saline into a 1 mL syringe. Inject the tracer into three distinct sites within the parenchyma of the outer upper quadrant of the breast. Following injection, perform gentle massage of the area for 5 minutes, then allow an additional 5 minutes for tracer distribution prior to proceeding with the surgical procedure. The SLNB was conducted through a curvilinear incision of approximately 5 cm along the posterior border of the pectoralis major muscle, following the natural transverse fold of the axillary skin. The anterior margin of the incision was carefully maintained within the anterior axillary line, with the option for controlled posterior extension when additional surgical exposure and access were necessary. The intraoperative frozen section analysis confirmed a negative SLNB.

Step 4: establishment of working space and docking

Identify the lateral border of the pectoralis major muscle through the axillary incision, and then the subpectoral, retromammary, and premammary spaces were carefully developed by 3 cm. The glandular tissue was sutured to the skin using silk sutures, while the pectoralis major fascia was closed to the skin with 3-0 Vicryl sutures. The pre-establishment of three well-defined surgical planes significantly enhanced operative efficiency and reduced robotic system setup time. During transitions between surgical planes, the color-coded sutures were selectively released in accordance with the predetermined surgical sequence, ensuring precise surgical exposure.

The wound protector was inserted into the axillary incision and connected to the four-channel unit port. To establish the air cavity, the inferior channel was attached to a constant-pressure insufflation device for CO2 insufflation, with the gas pressure set at 8 mmHg and an airflow rate maintained at 40 L/min. The robotic arms were positioned with an inter-arm distance of 5–10 cm, with fenestrated bipolar forceps mounted on Arm 2, the 30° endoscope on Arm 3, and monopolar curved scissors on Arm 4. These arms were assigned to specific channels: Arm 2 to the left-sided channel, Arm 3 to the superior channel, and Arm 4 to the right-sided channel. In most cases, the patient’s external position remains unchanged, as maintaining the upper extremity on the operative side abducted at 90° sufficiently accommodates the robotic arms’ movement requirements. However, under specific surgical circumstances, the upper extremity may be temporarily elevated and positioned above the head as dictated by the surgical needs.

Step 5: subpectoral space dissection

Upon entering the subpectoral space, the loose connective tissue between the pectoralis major and minor muscles was dissected using monopolar curved scissors. When reaching the origin of the pectoralis major, the tendinous attachments to the costal cartilage were divided. The dissection extended inferiorly to 1.5 cm below the inframammary fold, medially to 1 cm from the parasternal line, superiorly to the upper border of the fourth rib, and laterally to the anterior axillary line. We recommend dividing the pectoralis major muscle at a distance of 0.3–0.5 cm from its origin to avoid hemostatic challenges caused by perforator vessels bleeding and to preserve a small portion of muscle to cover the lower pole of the implant, which is considered a “defensive strategy”. During dissection, careful attention should be given to protecting the perforating vessels between the pectoralis major and minor muscles to prevent thermal injury from hemostasis and to reduce the risk of muscle atrophy. Additionally, maximal preservation of the intercostal nerves, particularly the anterior and lateral cutaneous branches, is essential for maintaining postoperative sensation in the NAC and skin (22).

Step 6: retromammary space dissection

The assistant cut the purple Vicryl sutures securing the pectoralis major fascia to the skin and gently adjusted the wound protector to expose the retromammary space over the surface of the pectoralis major. Using monopolar curved scissor, the loose connective tissue within the retromammary space was dissected, with division of the lateral suspensory ligament, horizontal septum, and medial suspensory ligament until the circum-mammary ligament was identified and divided (23,24). Following the division of the circum-mammary ligament, the surrounding breast tissue visibly descended, while the glandular tissue posterior to the NAC remained relatively fixed, creating a “tenting effect”. The key to this step is ensuring dissection along the correct surgical plane. With the assistance of insufflated gas, the Cooper ligaments can be visualized within the retromammary space between the deep layer of the superficial fascia and the superficial layer of the deep fascia. Using the Cooper ligaments as anatomical guides during meticulous dissection helps preserve the vascular structures within these fascial layers.

Step 7: premammary space dissection

Subsequently, the assistant cut the black silk sutures connecting the glandular tissue to the skin and adjusted the wound protector to expose the premammary space over the glandular surface. The surgeon, operating from the console, performed the dissection using monopolar curved scissors, following a general sequence: superior-lateral, superior-medial, inferior-lateral, and inferior-medial, with the area posterior to the NAC addressed last. During the dissection of the premammary space, fenestrated bipolar forceps were used to grasp the glandular tissue, maintaining appropriate tension. Given the lack of haptic feedback in the robotic system, the surgeon must rely on the degree of tissue separation to gauge the appropriate force. For surgical safety, gentle traction near the dissection point is recommended. The dissection of the premammary space represents the most challenging step of the procedure. The key strategy here is the accurate identification of the Cooper ligaments, which traverse the breast, anchoring it anteriorly to the skin and posteriorly to the pectoral fascia (25). Dissection should be performed along the Cooper ligaments, specifically between the superficial layer of the superficial fascia and the anterior lamella fat, using monopolar curved scissors. This approach ensures complete glandular removal while preserving the subdermal vascular and lymphatic networks.

Following complete or near-complete dissection of the premammary space, special attention must be given to the area posterior to the NAC. Because of the turning point of the superficial fascia behind the NAC, it lacks subcutaneous fat and loose connective tissue (26). Therefore, the surgeon should use blunt dissection with non-energy instruments to carefully separate the base of the nipple. Fenestrated bipolar forceps were employed to maintain tissue tension, while the base of the nipple was carefully severed with small cuts using monopolar curved scissors to minimize the risk of NAC ischemia and necrosis associated with thermal injury from energy devices. Throughout the dissection, careful observation and preservation of the areolar venous plexus (of Haller), are crucial to maintaining the blood supply to the NAC (27). Subsequently, tissues from the base of the nipple were excised and sent for intraoperative frozen section analysis. If tumor involvement is detected, NAC removal and subsequent reconstruction will be necessary. Upon completing all steps of the single-incision R-NSM, the breast specimen should remain intact and be removed through the wound protector.

Step 8: irrigation, drainage, and IBR

Irrigate the surgical cavity with 3,000 mL of warm sterile distilled water. Then, the implant pocket was soaked with 0.45–0.55% povidone-iodine solution for 10 minutes, followed by another irrigation with warm distilled water. A drainage tube was placed in both the superior and inferior aspects of the subcutaneous layer, with each tube connected to negative pressure suction.

Gloves should be changed before handling the implant. The implant was immersed in povidone-iodine for 10 minutes and then irrigated with sterile distilled water. Typically, mesh is not required for subpectoral reconstruction. Using an S-shaped retractor to expose the axillary incision and pectoralis major muscle, the implant was inserted into the subpectoral pocket and adjusted to the optimal position, with the upper portion positioned behind the pectoralis major and the lower portion behind the pectoralis major fascia. If necessary, the pectoralis major and minor muscles are sutured at the superior border of the implant to prevent upward displacement. The lateral borders of the pectoralis major and minor muscles were then sutured using 3-0 Vicryl to securely close the implant pocket. Finally, the subcutaneous tissue and skin were sutured in layers, thereby completing the surgical procedure.


Postoperative considerations and tasks

The breast and axilla were dressed with elastic bandages under appropriate pressure, taking care to avoid compression of the NAC. Prophylactic antibiotics were administered for 24 hours. Subsequently, the patient began to wear a pressure garment 24 hours after surgery (28). For the first three postoperative days, the shoulder joint on the affected side should be immobilized, avoiding abduction of the upper extremity. The volume and characteristics of the drainage were closely monitored and recorded. The drainage tube was considered for removal when the daily drainage volume consistently remained below 30 mL for three consecutive days. Special attention should be given to the blood supply to the NAC, with nitroglycerin applied to the NAC as needed to enhance perfusion. The total operative time for the patient was 190 minutes, with a console time of 80 minutes. Intraoperative blood loss was 20 mL. The patient experienced no postoperative complications. Postoperative routine pathology confirmed invasive breast cancer, with associated ductal carcinoma in situ (approximately 80%). No cancer invasion was observed at the peripheral margins or the base of the nipple. The patient was scheduled to receive standard adjuvant therapy in accordance with current guidelines. Follow-up evaluations were conducted at 1, 3, and 6 months postoperatively, followed by annual assessments thereafter.


Tips and pearls

During the robotic surgical procedure, the surgeon, positioned at the console, depends mainly on their comprehensive understanding and precise identification of anatomical structures to accurately determine the surgical resection margins, which is crucial for achieving optimal oncological and aesthetic outcomes. Consequently, a comprehensive knowledge of breast fascial anatomy is essential. For beginners, assistance can be provided by having the assistant apply pressure to the breast for localization or by preoperatively marking the resection margins with methylene blue (6,14).


Discussion

This video provides a detailed overview of all steps involved in single-incision R-NSM with IBR. The patient reported satisfaction with the aesthetic outcomes following surgery (Figure 2).

Figure 2 Postoperative outcomes. (A) The image shows the frontal view of the breast appearance at 7 days after surgery. (B) The image shows the lateral view of the breast appearance at 7 days after surgery.

Minimally invasive surgery is a key focus and area of innovation in modern surgical practice. E-NSM has been proven to provide reliable oncologic safety, improve patient satisfaction and postoperative aesthetic outcomes (9,10,29,30). It offers advantages such as smaller and more inconspicuous incisions, reduced complication rates, and particularly lower rates of NAC ischemia/necrosis (9,15,30). However, the two-dimensional endoscopic in-line camera generates an inconsistent optical window around the curvature of the breast skin flap with insufficient dissection angles (15,16). Additionally, surgeons must work with long instruments while viewing a screen with reduced haptic feedback, which diminishes fine motor control and complicates hand-eye coordination (31). These challenges are further compounded by the “chopstick effect” inherent to the single-port technique. These limitations have prevented E-NSM from gaining widespread global acceptance, with its implementation primarily concentrated in Asia (18). However, the robotic surgical system, featuring three-dimensional visualization, highly flexible robotic arms and instruments, and ergonomic and intuitive hand movements, has effectively overcome these limitations, making it well-suited for procedures in confined surgical spaces (13,32,33). In recent years, R-NSM has gained widespread recognition and adoption worldwide, contributing to advancements in minimally invasive breast surgery (5). This trend may be attributed to the shortened learning curve associated with the robotic approach (18,19).

Our technique differs from those previously reported in the literature. The single-incision gas inflation method is the most frequently used technique, with the incision typically located in the axilla or the lateral chest wall (14,21,34,35). We propose that a single axillary incision can accommodate all surgical procedures, including SLNB, potentially reducing postoperative pain and shortening recovery time. Additionally, compared to other populations, Asian individuals have a higher risk of developing hypertrophic scars following skin injury. Consequently, an incision hidden within the axilla is favored due to its superior aesthetic outcomes (36,37). Our previous study comparing axillary and lateral chest wall approaches in single-port E-NSM demonstrated that the lateral chest wall approach resulted in a shorter operative time and learning curve. Compared to the axillary approach, the lateral chest wall approach runs parallel to the breast without forming an angle, providing a greater range of instrument movement, wider visualization, and shorter optical working distance (38). These factors facilitate the surgeon’s operation and enhance the assistant’s control of the endoscopic camera. Current literature indicates that single-incision R-NSM achieves high patient satisfaction and good aesthetic outcomes regardless of incision location (5,9,14). However, no studies have directly compared the impact of incision location on surgical outcomes. During the procedure, maintaining the patient’s upper extremity in 90° abduction is sufficient to meet surgical requirements without restricting the movement of the robotic arms. Prolonged positioning of the upper extremity above the head may increase the risk of brachial plexus injury. In terms of surgical sequence, we adopt a “deep-to-superficial” approach. Compared to the “superficial-to-deep” dissection sequence, this technique effectively leverages gas tension to create a tent-like elevation of the breast tissue, thereby providing an adequate working space for subpectoral and retromammary space dissection (6,39). Initiating dissection in the premammary space first causes the mammary gland to descend due to gravity, which can obstruct the surgical field, limit the working space, and ultimately increase the difficulty of the dissection (32,39,40).

NAC ischemia/necrosis represents the most common and concerning complication, and its prevention is crucial for the success of NSM with IBR, directly impacting patient satisfaction and postoperative aesthetic outcomes (9,41). The primary factor influencing NAC ischemia/necrosis is its blood supply. Wuringer et al. first introduced the concept of the horizontal septum, which originates from the pectoral fascia at the level of the fifth rib and accompanies the major vessels and nerves supplying the breast and NAC (22). As a key component of the breast fascial system, the horizontal septum primarily functions to provide fascial support for the breast’s vascular supply, innervation, and glandular tissue (42). However, NSM inevitably disrupts the horizontal septum, leaving the NAC’s postoperative blood supply predominantly dependent on the subdermal vascular network formed by the perforating branches of the internal thoracic artery and the branches of the lateral thoracic artery, which run along the medial and lateral suspensory ligaments, respectively (22,43). The aforementioned surgical techniques and strategies have a positive impact on reducing NAC ischemia/necrosis. First, the axillary incision avoids any incisions around the NAC or on the breast skin, thereby reducing the risk of disruption to the subdermal vascular network. Second, the theory of breast fascial anatomy guides the surgeon in accurately identifying the anatomical layers and surgical resection margins (23). During the procedure, we employ a “defensive strategy”. In the dissection of the retromammary space, every effort is undertaken to preserve identifiable neurovascular bundles whenever possible, with proactive identification and management of potential bleeding sites. During the dissection of the premammary space, particular emphasis is placed on preserving the subdermal vascular network, lymphatic network, and venous plexus of Haller. The robotic surgical system excels in this regard, aiding the surgeon in better identifying anatomical structures and performing precise surgery. Additionally, researchers have utilized indocyanine green fluorescence imaging to evaluate NAC perfusion preoperatively, classifying it into three distinct patterns: predominantly derived from the underlying breast tissue (V1), the subdermal vascular network (V2), or a combination of V1 and V2 (V3). The findings showed that the V1 perfusion pattern had the highest rate of NAC ischemia/necrosis (44). Therefore, preoperative assessment of NAC perfusion patterns can provide valuable guidance for surgical planning and contribute to reducing the incidence of NAC ischemia/necrosis.

This study has several limitations that should be acknowledged. One of the primary limitations of R-NSM is its higher cost. A prospective study by Lai et al. demonstrated that the overall medical costs of R-NSM were approximately 4,000 USDs higher than those of C-NSM and 2,600 USDs more than E-NSM, significantly limiting its widespread adoption (9). Furthermore, R-NSM is associated with prolonged operative times, which may increase anesthesia-related risks and the incidence of perioperative complications (9,45). Importantly, as an emerging surgical technique, R-NSM is currently supported by limited follow-up duration and oncological data, and there is a lack of robust evidence confirming its long-term oncological safety (20). Therefore, large-scale, high-quality studies are needed to further evaluate its safety and feasibility. Although this paper provides a detailed introduction to the surgical technique of single-incision R-NSM with IBR, it remains a descriptive technical report based on a single case. We plan to continue collecting data from a larger patient cohort to obtain more comprehensive outcome data in the future.


Conclusions

The paper and video provide a step-by-step introduction to the surgical techniques, strategies, and key considerations of single-incision R-NSM with IBR. This resource may serve as an instructive reference for both beginners and peers in the field and facilitate the development of standardized and systematic surgical protocols.


Acknowledgments

This work was supported by National Key Clinical Discipline.


Footnote

Reporting Checklist: The authors have completed the SUPER reporting checklist. Available at https://gs.amegroups.com/article/view/10.21037/gs-2025-151/rc

Peer Review File: Available at https://gs.amegroups.com/article/view/10.21037/gs-2025-151/prf

Funding: None.

Conflicts of Interest: All authors have completed the ICMJE uniform disclosure form (available at https://gs.amegroups.com/article/view/10.21037/gs-2025-151/coif). The authors have no conflicts of interest to declare.

Ethical Statement: The authors are accountable for all aspects of the work in ensuring that questions related to the accuracy or integrity of any part of the work are appropriately investigated and resolved. All procedures performed in this study were in accordance with the ethical standards of the ethics committee of The Sixth Affiliated Hospital, Sun Yat-sen University and with the provisions of the Declaration of Helsinki and its subsequent amendments. Written informed consent was obtained from the patient for the publication of this article, accompanying images and the video. A copy of the written consent is available for review by the editorial office of this journal.

Open Access Statement: This is an Open Access article distributed in accordance with the Creative Commons Attribution-NonCommercial-NoDerivs 4.0 International License (CC BY-NC-ND 4.0), which permits the non-commercial replication and distribution of the article with the strict proviso that no changes or edits are made and the original work is properly cited (including links to both the formal publication through the relevant DOI and the license). See: https://creativecommons.org/licenses/by-nc-nd/4.0/.
